The Unicorn, as its name suggests is a very rare animal: a single driver loudspeaker that covers the full audio range. It uses a single carbon fibre DDD driver to cover the full range from 24kHz all the way down to 40Hz. The bass has a speed and smoothness of integration with the rest of the audio range that we have yet to hear bettered. The overall clarity, coherence and finesse the Unicorn provides make it a dream for lovers of vocal, jazz and classical music. It is also capable of surprising rock music fans.

Award Winning Loudspeaker

The unusual look of the German Physiks Unicorn MK II is dictated by the way it works

Form Follows Function

The Unicorn’s single DDD driver sits on top of a cabinet that houses a sophisticated horn system. Above about 200Hz the DDD driver radiates the sound directly, as it does on all other German Physiks loudspeakers. Below this, low frequency energy radiated from below the DDD driver is coupled to the horn system. This allows the low frequency response to be extended down to below 40Hz, however the speed and clarity of the bass gives the impression of even greater extension.

Using just one driver, the result is a loudspeaker with the exceptional resolution, speed and 3-dimensional stereo imaging we have come to expect from all German Physiks designs, plus an outstandingly clean and dynamic bass from the horn system. Bass, wind and string instruments are reproduced with a degree of fidelity rarely heard outside of the concert hall. If you are a horn loudspeaker aficionado, this could be the loudspeaker that you have been waiting for.

Ultra Fast Low Distortion Bass

Considerable work went into designing the Unicorn’s horn system. The final design comprises a high gain horn coupled with a tuned bass trap. The bass trap keeps mid-frequency energy out of the horn. This would otherwise lead to smearing due to time differences between the DDD driver’s direct radiation and the horn, as well as cause a bump in the mid frequency response. To achieve a completely even frequency response in the transition region, a small amount of equalisation is applied to the input signal by a network which is housed in a separate case. The excellent qualities the DDD driver shows in its normal mode of operation are exhibited in the bass produced by the horn. It is fast, agile and extremely clean. There is no hint of bloat or overhang and distortion is impressively low.

The DDD driver’s omnidirectional radiation characteristic and its very wide operating range, together with several other key features give the following important advantages to all German Physiks designs and is what sets them apart

1. Exceptionally coherent and natural sound

This is due to the DDD driver’s 7 octave plus operating range. This is very difficult to achieve when such a wide range is split over two or more different types of driver, which are in different positions on the loudspeaker’s cabinet.

This wide operating range also eliminates the crossover point in the mid-range that loudspeakers using pistonic drivers must have. This is where our hearing is most sensitive, so removing anything that might cause level or phase errors from here will improve transparency.

2. Realistic stereo images more like those you experience in the concert hall

This is because the DDD driver's omnidirectional radiation characteristic creates an enveloping sound field like that in the hall, rather than beaming the sound at you as conventional drivers do. This way the Unicorn MK II is able to recreate a more natural rendition of the original stereo image. This has excellent depth and focus, but without the overly sharp image definition that some hi-fi loudspeakers produce and which you will rarely if ever hear at a live performance.

3. Stereo imaging enjoyable in almost all positions in the room

This is achieved whilst also maintaining an even tonal balance, much like at a live performance: again due to the DDD driver’s omnidirectional radiation pattern. This gives more flexibility in where you sit and allows several people to enjoy a good sound together. This is useful in home theatre systems.

As you are not restricted to a small “sweet-spot” in order to hear the best sound, the Unicorn MK II provides a more relaxed listening experience. This is especially noticeable when you listen for long periods.

4. Exceptional dynamics

The DDD driver’s very low moving mass, less than 3 grams, allows German Physiks loudspeakers to recreate both the attack of the music and resolve low level detail very accurately. This is essential in order to faithfully reproduce the delicate nuances of a performance and make it sound like music, rather than just good hi-fi. The resultant transparency is maintained even on complex high-level passages.

5. Accurate portrayal of musical instruments’ tonal characteristics

This is because the DDD driver is phase linear across its operating range. This together with the excellent dynamic response, enables the Unicorn MK II to reproduce percussion with startling reality. Voices have a clarity and purity that can be breath taking, with all the elements of the vocal sound correctly located in space and with no undue emphasis. The hardness you often hear with conventional tweeters is eliminated and you get a greater sense of hearing a live musician.

6. Quick and easy to set up

As they are omnidirectional, German Physiks loudspeakers are less sensitive to room position than conventional designs and there is no toe-in adjustment to worry about.

7. The DDD driver is less likely to excite cabinet vibrations

Due to its very low moving mass and the way that it is mounted, the DDD driver puts less energy into the cabinet than an equivalent conventional driver. This reduces cabinet resonances and improves transparency.

8. Physically extremely rugged

The DDD driver can withstand abuse that will destroy most other drivers. Thisis illustrated in the video below. We don’t advise our customers to try this, just in case they are having an unlucky day.

For a more detailed explanation of these points, please follow this link.

More information on the DDD driver, its development and advantages, please follow this link.
